Android 中 viewpager 滑动指示器的实例代码

public class MainActivity extends FragmentActivity {   private ViewPagerFrameAdapter adapter;  //适配器（标题和内容）  private ViewPager mPager;         private TabPageIndicator   tabbPageIndicator;   //  private UnderlinePageIndicatorEx underlinePageIndicator;  private int COUNT = 0;  private List<String> titles = new ArrayList<String>(); //标题  @Override  protected void onCreate(Bundle bundle) {     super.onCreate(bundle);     requestWindowFeature(Window.FEATURE_NO_TITLE);     setContentView(R.layout.activity_main);     //标题，这里自己造的假数据     for (int j = 0; j < 3 ; j++){      titles.add( "第"+ j +"标签卡");     }     mPager = (ViewPager)findViewById(R.id.pager);     adapter = new ViewPagerFrameAdapter(getSupportFragmentManager(),titles);     mPager.setAdapter(adapter);     //得到指示器     tabbPageIndicator = (TabPageIndicator) findViewById(R.id.tab_indicator);      tabbPageIndicator.setViewPager(mPager);     //下标     underlinePageIndicator = (UnderlinePageIndicatorEx)findViewById(R.id.underline_indicator);     underlinePageIndicator.setViewPager(mPager);     underlinePageIndicator.setFades(false);     //设置指示器     tabbPageIndicator.setOnPageChangeListener(underlinePageIndicator);  }  //adapter 没啥好说的 跟前面的一样  private class ViewPagerFrameAdapter extends FragmentStatePagerAdapter{   private List<String> title; //页面标题头部数据   public ViewPagerFrameAdapter(FragmentManager fm, List<String> title) {    super(fm);    this.title = title;   }   //根据position 返回 fragment   @Override   public Fragment getItem(int position) {    return ArrayFragment.newInstance(position);   }   //size   @Override   public int getCount() {     return title.size();   }   //顶部的title   @Override   public CharSequence getPageTitle(int position) {    if (titles != null){     return titles.get(position).toString();    }    return super.getPageTitle(position);   }   } }

//继承这个然后重写 public class UnderlinePageIndicatorEx extends UnderlinePageIndicator{   public UnderlinePageIndicatorEx(Context context) {    super(context, null);     }   public UnderlinePageIndicatorEx(Context context, AttributeSet attrs) {    super(context, attrs, R.attr.vpiUnderlinePageIndicatorStyle);    }   public UnderlinePageIndicatorEx(Context context, AttributeSet attrs, int defStyle) {    super(context, attrs, defStyle);     }   //自身的 ViewPage传递过去   @Override   public void setViewPager(ViewPager viewPager) {    if (mViewPager == viewPager){     return;    } //   if (mViewPager != null) { //    mViewPager.setOnPageChangeListener(null); //   }    if (viewPager.getAdapter() == null) {     throw new IllegalStateException(" pager 没有 加入 adapter");    }    mViewPager = viewPager; //   mViewPager.setOnPageChangeListener(this);    invalidate();    post(new Runnable(){     @Override public void run() {      if (mFades) {       post(mFadeRunnable);      }     }     });   } }

public class ArrayFragment extends Fragment{  private int position;  public ArrayFragment(int position){   this.position = position;  }   // 返回 viwePager 下面滑动的页面  public static ArrayFragment newInstance(int position){   return new ArrayFragment(position);  }  @Override  public void onCreate(Bundle savedInstanceState) {   super.onCreate(savedInstanceState);  }  @Override  public void onDestroy() {   super.onDestroy();  }  // 根据position 返回不同的view  @Override  public View onCreateView(LayoutInflater inflater, ViewGroup container,    Bundle savedInstanceState) {   View view = inflater.inflate(R.layout.layoutaa, null);    return view;  } }

<LinearLayout   xmlns:android="http://schemas.android.com/apk/res/android"   android:layout_width="fill_parent"   android:layout_height="fill_parent"   android:orientation="vertical"   >  <!-- 标题  和  标题下面的 指示器 -->   <LinearLayout   android:layout_width="fill_parent"   android:layout_height="35dp"   android:orientation="vertical"   android:background="@drawable/main_header_background">     <com.viewpagerindicator.TabPageIndicator      android:id="@+id/tab_indicator"      android:layout_height="wrap_content"      android:layout_width="fill_parent"/>     <com.test.linepagerindictor.widget.UnderlinePageIndicatorEx      android:id="@+id/underline_indicator"      android:layout_height="3dip"      android:layout_width="fill_parent"      android:layout_alignParentBottom="true"/>   </LinearLayout>    <android.support.v4.view.ViewPager   android:id="@+id/pager"   android:layout_width="fill_parent"   android:layout_height="fill_parent"/>  </LinearLayout>

<!-- 总 style 直接引用 这个 由 tab style 和 Indicator style 组成 -->  <style name="StyledAllIndicators" parent="@android:style/Theme.Light">   <item name="vpiTabPageIndicatorStyle">@style/CustomTabPageIndicator</item>   <item name="vpiUnderlinePageIndicatorStyle">@style/CustomUnderlinePageIndicator</item>  </style>  <!-- tab的 style -->  <style name="CustomTabPageIndicator" parent="Widget.TabPageIndicator">   <item name="android:background">#00000000</item>   <item name="android:textAppearance">@style/CustomTabPageIndicator_text</item>   <item name="android:textColor">@color/selector_tab</item>   <item name="android:textSize">20sp</item>   <!-- 分割线，可有可无的 -->   <item name="android:divider">@drawable/custom_tab_indicator_divider</item>   <item name="android:dividerPadding">10dip</item>   <item name="android:showDividers">middle</item>   <item name="android:paddingTop">4dp</item>   <item name="android:paddingLeft">8dp</item>   <item name="android:paddingBottom">4dp</item>   <item name="android:paddingRight">8dp</item>   <item name="android:fadingEdge">horizontal</item>   <item name="android:fadingEdgeLength">8dp</item>  </style>  <style name="CustomTabPageIndicator_text" parent="android:TextAppearance.Medium">   <item name="android:typeface">monospace</item>  </style>  <!-- 下标的指示器的颜色 -->  <style name="CustomUnderlinePageIndicator">   <item name="selectedColor">#EB5548</item>   <item name="android:background">#00000000</item>   <item name="fadeLength">1000</item>   <item name="fadeDelay">1000</item>  </style>

<?xml version="1.0" encoding="utf-8"?> <selector xmlns:android="http://schemas.android.com/apk/res/android">  <item android:state_selected="true" android:color="#91D228" />  <item android:state_focused="true" android:color="#91D228" />  <item android:color="#dddddd" /> </selector>
